| Part No. | Pattern | Tire Size | Ply Rating | Load Index Speed Rating | Overall Diameter (inch) | Section Width (inch) | Rim Size (inch) | Inflaed Pressure (psi) | Max. Load (Ibs) | Tread Depth (mm) |
| V23001 | AR30 | 27x9.00R14 | 6 | 60L | 27.2 | 8.8 | 14x7.0 | 22 | 550 | 18 |
| V23002 | AR30 | 27x11.00R14 | 6 | 66L | 27.2 | 10.8 | 14x9.0 | 22 | 660 | 18 |
| V23005 | AR30 | 29x9.00R14 | 8 | 84J | 29.4 | 9 | 14x7.0 | 32 | 1100 | 20 |
| V23006 | AR30 | 29x11.00R14 | 8 | 90J | 29.4 | 11 | 14x9.0 | 34 | 1320 | 20 |
| V23003 | AR30 | 30x10.00R14 | 8 | 70M | 30.3 | 10.2 | 14x8.0 | 30 | 740 | 18.5 |
| V23004 | AR30 | 30x10.00R15 | 8 | 69M | 30.3 | 10.2 | 15x8.0 | 30 | 715 | 18.5 |
